README.md
ANE Training — Stories110M on Apple Neural Engine
Training a 109M-parameter Llama2-architecture transformer (Stories110M) directly on Apple's Neural Engine using private ANE APIs.
Architecture
- Model: Stories110M — dim=768, hidden=2048, heads=12, layers=12, vocab=32000, seq=256
- 109.53M params (84.95M transformer + 24.58M embedding)
- 72 ANE kernels per compile (60 weight-bearing, 12 weight-free sdpaBwd2)
- 6 kernel types per layer: fwdAttn, fwdFFN, ffnBwd, sdpaBwd1, sdpaBwd2, qkvBwd
Performance
| Component | Time (ms/step) |
|---|---|
| ANE eval | 9.6 |
| IO (fp16 conversion) | 4.1 |
| Classifier (cblas) | 9.1 |
| Cross-entropy + residuals | 14.4 |
| RMSNorm | 0.1 |
| Total | 107 ms/step |
Files
| File | Description |
|---|---|
train_large.m |
Main training loop — 12-layer forward/backward, checkpoint, exec() restart |
stories_config.h |
Model config, structs, alloc helpers |
stories_io.h |
IOSurface I/O, NEON fp16 conversion, kernel compile/eval |
stories_mil.h |
MIL program generators for all 6 ANE kernel types |
stories_cpu_ops.h |
vDSP-vectorized RMSNorm, cross-entropy, Adam, embedding ops |
dashboard.py |
TUI dashboard — loss curve, power/CPU/memory graphs, text generation |
tokenize.py |
Extract pretokenized TinyStories data |
Makefile |
Build targets |
How it works
-
Forward pass: Each layer runs fwdAttn (QKV + SDPA + Wo) and fwdFFN (W1 + SiLU(W3) + W2) on ANE via MIL-compiled kernels. Final RMSNorm + classifier matmul on CPU (cblas).
-
Backward pass: Reverse layer order. ffnBwd, sdpaBwd1, sdpaBwd2, qkvBwd on ANE. Weight gradients (dW) via async cblas_sgemm on CPU. RMSNorm backward via vDSP.
-
Compile budget: ANE has a ~119 compile limit per process. With 72 kernels per batch, we run 10 accumulation steps then
exec()restart with checkpoint resume. -
Data: Real TinyStories text (20M tokens), mmap'd uint16 token IDs, random position sampling per step.
Usage
# Extract tokenized data
python3 tokenize.py
# Build and train
make train_large
./train_large # fresh start
./train_large --resume # resume from checkpoint
# Monitor with dashboard
pip install blessed psutil numpy
python3 dashboard.py --resume # needs sudo for powermetrics
Key techniques
- NEON vectorized fp16<->fp32: ARM NEON intrinsics for fast IOSurface data transfer
- vDSP cross-entropy:
vDSP_mtrans+vvexpf+vDSP_sve— 8x faster than scalar - Async weight gradients: cblas_sgemm dispatched to background queue, overlapped with ANE
- SDPA causal mask workaround: ANE hardware ignores attn_mask, so we decompose attention into Q@K^T (ANE conv) + mask+softmax (CPU) + scores@V (ANE conv)
