ANE Training — Stories110M on Apple Neural Engine

Training a 109M-parameter Llama2-architecture transformer (Stories110M) directly on Apple's Neural Engine using private ANE APIs.

Architecture

• Model: Stories110M — dim=768, hidden=2048, heads=12, layers=12, vocab=32000, seq=256
• 109.53M params (84.95M transformer + 24.58M embedding)
• SDPA causal mask workaround: ANE hardware ignores attn_mask — decompose into Q@K^T (ANE conv) + mask+softmax (CPU) + scores@V (ANE conv)

Three Training Pipelines

1. Static Baseline (train_large)

Original pipeline. Weights baked as constants in MIL kernels — recompile every 10 steps via exec() restart.

• 60 weight-bearing + 12 weight-free kernels = 72 per compile batch
• Classifier + softmax + RMSNorm backward on CPU
• 106.7 ms/step, 7.6s compile per restart

2. Static + ANE Extras (train_large_ane) — PR#19

Offloads classifier forward (32K conv), softmax, final RMSNorm, and RMSNorm backward to ANE. Bridge API for C-callable ANE access.

• 86 kernels per compile batch (+24 rmsnorm_bwd, +1 classifier, +1 finalRms)
• 91.8 ms/step (14% faster), 9.6s compile per restart
• Use --no-ane-extras to disable and fall back to CPU (for debugging)

3. Dynamic Weight Pipeline (training_dynamic/)

Weights passed via IOSurface spatial dimension — compile 9 kernels once at startup, no recompilation needed.

• 9 shared kernels across all 12 layers
• 111 ms/step, 0.4s one-time compile
• No exec() restart, no compile limit issues

Performance Comparison (20 Steps)

	Static Baseline	PR#19 + ANE extras	PR#19 no extras	Dynamic
Wall time	10.1s	11.7s	10.7s	~2.6s
Compile	7.6s (75.7%)	9.6s (81.6%)	7.5s (69.7%)	0.4s (15%)
Train	2.1s (21.2%)	1.8s (15.6%)	2.9s (27.4%)	2.2s (85%)
ms/step	106.7	91.8	147.0	111
Kernels/restart	72	86	60	9 (once)
ANE TFLOPS	0.87	1.15	0.72	—
Total TFLOPS	1.63	1.90	1.19	—

Key insights:

• Dynamic wins on wall time for any practical run length (3.9x faster at 20 steps)
• PR#19 has the best per-step throughput (92ms) but compile overhead dominates short runs
• Static restarts every 10 steps, so dynamic's zero-recompile advantage compounds

Files

File	Description
train_large.m	Static baseline — 72 kernels, classifier/softmax on CPU
train_large_ane.m	PR#19 — 86 kernels, classifier/softmax/rmsnorm_bwd on ANE
training_dynamic/train.m	Dynamic pipeline — 9 kernels, weights via IOSurface
training_dynamic/mil_dynamic.h	MIL generators for dynamic weight kernels
training_dynamic/config.h	Model config (DIM=768, HIDDEN=2048, etc.)
training_dynamic/io.h	IOSurface I/O + MIL compilation helpers
training_dynamic/cpu_ops.h	CPU ops (SiLU backward, cross-entropy, Adam)
stories_config.h	Static pipeline config, structs, alloc helpers
stories_io.h	IOSurface I/O, NEON fp16 conversion, kernel compile/eval
stories_mil.h	MIL generators for static pipeline (6 kernel types)
stories_cpu_ops.h	vDSP-vectorized RMSNorm, cross-entropy, Adam
ane_classifier.h	ANE classifier fwd (32K conv), softmax kernels
ane_rmsnorm_bwd.h	ANE rmsnorm backward kernel
dashboard.py	TUI dashboard — loss curve, power/CPU/memory graphs
Makefile	Build targets

Usage

1. Download Training Data

bash download_data.sh

Downloads pretokenized TinyStories (Llama 2 BPE, 32K vocab) from HuggingFace. Produces tinystories_data00.bin (~41 MB, ~20M tokens).

2. Build & Train

# Static baseline (classifier + softmax on CPU)
make train_large
./train_large stories110M.bin 256 100 1e-4
./train_large --model stories110M.bin --steps 100 --lr 1e-4

# PR#19: ANE-offloaded classifier + softmax + rmsnorm_bwd
make train_large_ane
./train_large_ane stories110M.bin 256 100 1e-4
./train_large_ane --no-ane-extras --steps 100    # disable ANE extras

# Dynamic pipeline (no recompilation)
cd training_dynamic && make train
./train --scratch              # train from random init
./train                        # resume from checkpoint
./train --steps 200 --lr 1e-4  # custom steps/lr

CLI flags (all pipelines):

• --steps N (default 10000)
• --lr F (default 3e-4)
• --model PATH — pretrained weights file
• --ckpt PATH — checkpoint file (preserved across exec() restarts)
• --resume — resume from checkpoint
• --no-ane-extras — (train_large_ane only) disable ANE classifier/softmax/rmsnorm_bwd

3. Monitor with Dashboard

pip install blessed psutil numpy
sudo python3 dashboard.py          # static pipeline
sudo python3 dashboard.py --dynamic # dynamic pipeline

4. Benchmarking

All programs print an Efficiency Report at completion:

=== Efficiency Report ===
Total steps:     20
Wall time:       11738 ms (11.7 s)
Compile time:    9583 ms (81.6%)
Train time:      1835 ms (15.6%)
Avg train:       91.8 ms/step
ANE TFLOPS:      1.15 sustained

Key Techniques

• NEON vectorized fp16↔fp32: ARM NEON intrinsics for fast IOSurface data transfer
• vDSP cross-entropy: vDSP_mtrans + vvexpf + vDSP_sve — 8x faster than scalar
• Async weight gradients: cblas_sgemm dispatched to background queue, overlapped with ANE
• Vocab compaction (dynamic): 32K → 9.2K active tokens, 3.5x reduction in classifier work
• Dynamic weight packing: Activations + weights concatenated in IOSurface spatial dimension — one kernel serves all 12 layers
• exec() restart: Workaround for ANE ~119 compile limit per process
