ANE Training — Stories110M on Apple Neural Engine

Training a 109M-parameter Llama2-architecture transformer (Stories110M) directly on Apple's Neural Engine using private ANE APIs.

Architecture

• Model: Stories110M — dim=768, hidden=2048, heads=12, layers=12, vocab=32000, seq=256
• 109.53M params (84.95M transformer + 24.58M embedding)
• 72 ANE kernels per compile (60 weight-bearing, 12 weight-free sdpaBwd2)
• 6 kernel types per layer: fwdAttn, fwdFFN, ffnBwd, sdpaBwd1, sdpaBwd2, qkvBwd

Performance

Component	Time (ms/step)
ANE eval	9.6
IO (fp16 conversion)	4.1
Classifier (cblas)	9.1
Cross-entropy + residuals	14.4
RMSNorm	0.1
Total	107 ms/step

Files

File	Description
train_large.m	Main training loop — 12-layer forward/backward, checkpoint, exec() restart
stories_config.h	Model config, structs, alloc helpers
stories_io.h	IOSurface I/O, NEON fp16 conversion, kernel compile/eval
stories_mil.h	MIL program generators for all 6 ANE kernel types
stories_cpu_ops.h	vDSP-vectorized RMSNorm, cross-entropy, Adam, embedding ops
dashboard.py	TUI dashboard — loss curve, power/CPU/memory graphs, text generation
tokenize.py	Extract pretokenized TinyStories data
Makefile	Build targets

How it works

1. Forward pass: Each layer runs fwdAttn (QKV + SDPA + Wo) and fwdFFN (W1 + SiLU(W3) + W2) on ANE via MIL-compiled kernels. Final RMSNorm + classifier matmul on CPU (cblas).

2. Backward pass: Reverse layer order. ffnBwd, sdpaBwd1, sdpaBwd2, qkvBwd on ANE. Weight gradients (dW) via async cblas_sgemm on CPU. RMSNorm backward via vDSP.

3. Compile budget: ANE has a ~119 compile limit per process. With 72 kernels per batch, we run 10 accumulation steps then exec() restart with checkpoint resume.

4. Data: Real TinyStories text (20M tokens), mmap'd uint16 token IDs, random position sampling per step.

Usage

1. Download Training Data

bash download_data.sh

Downloads pretokenized TinyStories (Llama 2 BPE, 32K vocab) from enio/TinyStories on HuggingFace. Produces tinystories_data00.bin (~41 MB, ~20M tokens).

2. Build & Train

# Baseline: classifier + softmax on CPU
make train_large
./train_large --steps 100        # quick test
./train_large                    # full 10k steps
./train_large --resume           # resume from checkpoint

# ANE-offloaded: classifier + softmax on ANE (faster)
make train_large_ane
./train_large_ane --steps 100

CLI flags: --steps N (default 10000), --lr F (default 3e-4), --resume.

3. Monitor with Dashboard

pip install blessed psutil numpy
sudo python3 dashboard.py          # live mode (needs powermetrics)
sudo python3 dashboard.py --resume  # attach to resumed training

4. Benchmarking

Both programs print an Efficiency Report at completion:

=== Efficiency Report ===
Total steps:     100
Avg train:       107.0 ms/step
ANE TFLOPS:      2.45 sustained
ANE utilization: 15.5% of 15.8 TFLOPS

Per-batch timing breakdown during training:

ane=9.6 io=4.1 cls=9.1 elem=14.4 rms=0.1 cblas_wait=2.3 ms/step

Metric	What it measures
ane	ANE kernel evaluation
io	fp16↔fp32 IOSurface transfer
cls	Classifier matmul (CPU cblas)
elem	Embedding, residual adds, cross-entropy
rms	RMSNorm forward/backward
cblas_wait	Waiting for async dW gradient sgemms

Compare baseline vs ANE-offloaded:

make train_large && ./train_large --steps 100
make train_large_ane && ./train_large_ane --steps 100

Key techniques

• NEON vectorized fp16<->fp32: ARM NEON intrinsics for fast IOSurface data transfer
• vDSP cross-entropy: vDSP_mtrans + vvexpf + vDSP_sve — 8x faster than scalar
• Async weight gradients: cblas_sgemm dispatched to background queue, overlapped with ANE
• SDPA causal mask workaround: ANE hardware ignores attn_mask, so we decompose attention into Q@K^T (ANE conv) + mask+softmax (CPU) + scores@V (ANE conv)
